Introducing LaunchBase Origin

HiArc's embedded hardware controller, LaunchBase Origin, is the first HiArc Printed Circuit Board Assembly (PCBA) that has been refined through decades of medical instrumentation innovation, to help empower our clients through their development process with enterprise-level precision and speed.



For over 45 years, our LaunchBase technology has powered some of the leading Life Science diagnostic instrumentation platforms, while maintaining ISO 13485 regulation standards and executing against tight cost and timeline requirements.
Professionals-sharing-expertise
Experience LaunchBase
PCBv2-gigapixel-high-fidelity-v2-2x_RT (1)
LaunchBase

Learn more

A team member will be in touch shortly.

Thank you, we'll be in touch soon

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

Stepper Motors

The board has 6 stepper motor drivers, with and without feedback, for handling multiple motion control scenarios for your device.

Interconnection Interface

The interconnect interface can be used as consolidated connections for stepper motors with feedback mechanisms and limits, minimizing cable design.

Reset

The reset button is a standard feature on all boards.

Opto-Sensor Input

The board provides a large number of optical sensor inputs, which are typically used for limit switches and general opto-sensors.

FAN Driver

The board provides multiple FAN drivers for controlling up to 4 separate channels.

Brush DC Driver

The board provides a brushed DC motor with multiple control modes.

Brushless DC Driver

The board has motor drivers that can operate a 3 phase BLDC motor with or without the use of feedback sensors.

Encoder Inputs

The board provides connections for several individual encoder inputs, with selectable feedback modes.

Analog Input

Besides the digital inputs, the board also provides multiple digitally controlled analog input channels to interface with a variety of sensors.

Pulsed Width Modulation (PWM) Driver

The board comes with multiple PWM channels for working with a variety of actuators and third-party controllers.

Power In

This is the nominal power connector for the board.

Power Out

The board has provision to supply power out of the board in cases where an external device needs power.

Protection

The board offers three types of protection - Service, Interlock and Safety.

External Communications

The board offers multiple types of external communications, including various serial communication methods such as RS485.

Ethernet

The board has an RJ45 connector for ethernet communications.

Microcontroller

The microcontroller is the brains of the board and comes pre-installed and programmed to be used in your embedded system design.

Accelerated development, engineered around your needs



LaunchBase Origin is an off-the-shelf tool expertly designed with nearly limitless possibilities by incorporating circuits for both common functionality as well as options for specialized functions.

  • Adaptable: Wide range of functions, including, but not limited to:

    • Servo and stepper motor control

    • Fluidic pumps and sensors

    • Temperature and humidity control

  • Scalable: Use just one board, or connect multiple boards to expand the functionality required for even the most complex of projects

  • Ready-to-use: Reference schematics and designs to jumpstart your project using an integrated SOM for out of the box functionality

Looking to develop a custom controller board for in-product use?

Connect with a HiArc expert to see how we can customize your hardware needs to collaborate on your vision, allowing you to stay in total control over your project.
